SUCCESSFUL EXPORT CASES FOR SNSC LPG GASOLINE 2.5 TONS FORKLIFT
TRUCK
In 2016 year, AUSTRALIA customer ordered 3 units FL25 2.5 ton LPG &
Gasoline forklift from us,
With JAPAN NISSAN K25 ENGINE, triplex full free 4.5m lift mast,
side shifter, solid tyre, electric hydraulic transmission. Customer
satisfyed our forklifts very much.
Main Features for SNSC LPG GASOLINE POWERED 2.5 TONS FORKLIFT TRUCK
1) with original Japan NISSAN K25 gasoline engine;
2) with auto electric hydraulic transmission by finger with TCM
technology, just use your finger that can achieve the forklift's
forward and backward;
3) with USA IMPCO converter;
4) with CE, ISO, GHOST certificates, quality is guaranteed;
5) with JAPANESE hydraulic system, like JAPAN SHIMADZU brand
hydraulic pump and valves;
6) with USA EATON brand steering gear, which makes our snsc
forklift have longer working life;
7) SNSC FL25 lpg gasoline forklift truck can install different
attachments to help your work, like paper roll clamp, side shifter,
full free container mast, bale clamp, button clamp, block clamp,
cabin.
Specifications of SNSC LPG GASOLINE 2.5TONS FORKLIFT TRUCK
| FD25 LPG GASOLINE FORKLIFT TRUCK SPECIFICATIONS |
| No. | Specifications | Unit | FD25 |
| 1 | 1 | Characteristics | Power | | LPG GASOLINE |
| 2 | 2 | Rated Capacity | kg | 2500 |
| 3 | 3 | Center of load | mm | 500 |
| 4 | 4 | Lifting height | mm | 3000 |
| 5 | 5 | Free lifting height | mm | 135 |
| 6 | 6 | Forks L×W×H | mm | 1070x122x40 |
| 7 | 7 | Tilt Forward/Backward | . | 6/12 |
| 8 | 8 | Min.turning radius | mm | 2240 |
| 9 | 9 | Min.ground clearance(Mast) | mm | 110 |
| 10 | 10 | Overhead guard height | mm | 2120 |
| 11 | 11 | Height from seat to overhead guard | mm | 943 |
| 12 | 12 | Front overhang | mm | 473 |
| 13 | 13 | Perf | Max.traveling speed(loaded) | km/h | 19 |
| 14 | 14 | Max.lifting speed(loaded/empty) | mm/s | 470/510 |
| 15 | 15 | Drawbar pull/Gradeability | kN/% | 17/20 |
| 16 | 16 | Dimensions | Overall length (without fork) | mm | 2570 |
| 17 | 17 | Overall width | mm | 1175 |
| 18 | 18 | Mast lowered height | mm | 1990 |
| 19 | 19 | Mast extended height | mm | 4000 |
| 20 | 20 | Chassis | Tire | Front | | 7.00-12-12PR |
| 21 | 21 | Rear | | 6.00-9-10PR |
| 22 | 22 | Wheelbase | mm | 1600 |
| 23 | 23 | Tread width | Front/Rear | mm | 970/970 |
| 24 | 24 | Curb weight | None-load | kg | 3750 |
| 25 | 25 | Powertrain | Battery | Voltage/Capacity | V/Ah | 12/90 |
| 26 | 26 | Engine | Model | | original japan nissan k25 engine |
| 27 | 27 | Rated power | kw/r.p.m | 37.4/2300 |
| 28 | 28 | Rated torque | Nm/r.p.m | 176.5/1600 |
| 29 | 29 | Cylinder amount | | 4 |
| 30 | 30 | Bore×Stroke | mm | 89×100 |
| 31 | 31 | Displacement | | 2.488 |
| 32 | 32 | Fuel tank | L | 60 |
| 33 | 33 | Transmission | 1/1 automatic transmission |
| 34 | 34 | Working pressure | MPa | 17.5 |
Our Factory Introduction
We, SNSC fork lifter factory, are top 3 fork lifter montacargas
manufactures and top 20 in the world. with 130,000 square meters
production area, over 500 employees,30,000 units forklifter diesel
truck production capacity per year,5000 sets export volume.
We are big fork lifter manufacture not small maker. We are
responsible for our customers and forklifts.
''QUALITY LEADING THE FUTURE" is our belief for ever.
We'd like to offer our best quality fork lifters to our customers
from all over the world.
Package and delivery:
One 20'GP containr can hold 3 units 2.5tons gasforklifts;
one 40'GP container can hold 6units 2.5ton petrol engine forklift
trucks.
Related SNSC forklift products
1. Counter Balanced Diesel powered forklift truck range from 1.5 to
10ton;(FD30,FD35,FD40,FD45,FD50,FD60,FD70,FD80,FD100)
2. Battery powered electric forklift truck range from 1.5 to
3.5ton;
(FB15, FB20, FB25, FB30, FB35)
3. Counter Balanced LPG and gasoline powered dual fuel forklift
trucks range from 1.5 to 3.5 ton;
(FL15, FL18, FL20, FL25, FL30, FL35)
4. warehouse equipments, like electric pallet truck, electric reach
truck, electric stacker & electric trailer, scissor lift, double
deep electric reach truck, racks.
If you have interests in our forklift, welcome you to contact
Nicole.
