AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker

Jinan Shine International Trade Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker from wholesalers

    Buy cheap AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker from wholesalers
    • Buy cheap AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker from wholesalers
    • Buy cheap AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker from wholesalers
    • Buy cheap AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker from wholesalers
    • Buy cheap AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker from wholesalers
    • Buy cheap AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker from wholesalers

    AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker

    Ask Lasest Price
    Brand Name : snsc
    Certification : CE/ISO
    Price : negotiable
    Delivery Time : 30-45 Days
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500/Months
    • Product Details
    • Company Profile

    AC Motor Rider 2.0tons Electric Stacker Truck / Reach Pallet Stacker

    Our Electric Stackers are equipped with advanced battery technology, providing extended run times and reduced charging cycles. With battery-operated stackers, you can eliminate the need for fuel and reduce carbon emissions, contributing to a greener and more sustainable workplace.
    Choose from our wide range of Electric Stackers, including the 1.2Ton 1.5Ton Economic Walkie Electric Stacker, 1.5Ton Walking Type Electric Stacker, 1.5Ton Stand On Type Electric Stacker, 2Ton Electric Stacker. Each model is designed with precision engineering and built to deliver exceptional performance, durability, and reliability.


    AC Motor Rider 2.0tons Electric Stacker for Sale
    Characteristics1.1modelDB20-R1
    1.2drivebattery
    1.3operator typestahngding
    1.4load capacityQ(kg)2000
    1.5load centrec(mm)600
    1.6front overhangx(mm)701
    1.7wheel baseY(mm)1325
    weight2.1capacity(with battery)kg1340
    2.2axle loading ,unladen(front/rear)kg1260/2080
    2.3axle loading ,laden(front/rear)kg920/420
    wheels chassis3.1tyres typepolyurethane
    3.2wheel size (front)φ230×75
    3.3wheel size (rear)φ80×70
    3.4additional wheelsφ125×50
    3.5wheels ,number front/rear (x = drven wheels)1x+2/4
    3.6track width (front)b10(mm)620
    3.7track width (rear)b11(mm)500
    dimentions4.1ciosed mast heighth1(mm)2030
    4.2lifting heighth3(mm)3000
    4.3height ,mast extendedh4(mm)3550
    4.4height of tiller in driving position min/maxh14(mm)1042/1410
    4.5height ,fork loweredh13(mm)90
    4.6lengthl1(mm)2054
    4.7length to face of forksl2(mm)904
    4.8widthb1(mm)850
    4.9fork dimentionss/e/l(mm)60/185/1150
    4.10width across forksb5(mm)685
    4.11ground clearance centre of wheelbasem2(mm)29
    4.12aisel width,pallet 1000x1200(1200crossways)Ast(mm)2504
    4.13aisel width,pallet 800x1200(1200lengthways)Ast(mm)2437
    4.14turning radiusWa(mm)1598
    Dimensions5.1travel speed ,laden/unladenKm/h5/5.5
    5.2lifting speed laden/unladenm/s0.08/0.12
    5.3lowering speed , laden/unladenm/s0.13/0.18
    5.8max.grade ability, laden/unladen%4/10
    5.1service brakeelectromagnetic
    motor6.1drive motor powerkW1.5(AC)
    6.2lift motor powerkW3(DC)
    6.4battery voltage/rated capacityV/Ah24/285
    6.5battery weightkg260
    others8.1type of dirve controlAC
    8.2soundlevel at the driver's sear according to DIN12053dB(A)70

    AC Motor Rider 2.0tons Electric Stacker for Sale
    Performance

    Robust Structure;

    Highly specialized drive and hydraulic system ensure excellent driving;

    Low-noise and durable hydraulic unit,high quality cylinder as well as hose ensure high reliability of hydraulic system;

    AMP connector and durable electric wires greatly reduce malfunctions of components.

    Straddle Chassis option offers stability of high stack operation.

    Safety

    Safe hydraulic design prevents mast from falling down abruptly when oil pipes cuts off.

    Belly button prevents truck from hitting operator

    By simply pressing emergency disconnector,power supply will be immediately interrupted.

    Multiple lifting limited switch ensures travel safety.

    Truck automatically switches to low speed mode,when lifting height is higher than setting height.

    Anti-rolling back braking device ensures trucks don't roll back on ramps

    Operation

    Ergonomic tiller head for effortless and comfortable operations.

    Tiller with long arm for smooth steering.

    Compact chassis design offers smallest turning radius needed.

    Side operating ensures excellent visibility.

    On-board Charge.

    Maintenance

    Maintenance-free Battery

    Battery display indicator with hour meter,reminds operator of charging on time(optional).

    Easy Maintenance-detachable rearpanel.

    Self-Diagnostics signal on the digital disply allows easy trouble-shooting.

    Easy Accessof hand Set.

    Low-Voltage Cut-off Protection.

    Packing & Delivery
    1.5tons electric forklift will use container shipment or Ro-Ro shipment to delivery;
    one 20GP container can take 4pcs 1.5tons electric forklift;
    one 40GP container can take 6pcs 1.5tons electric forklift.

    Chose us
    Long history and stable factory background:
    A history of over 24 years;
    Technology ranks NO.1 in China;
    Annual out put nearly 30,000 units.

    High-quality and reliable products:
    Upgrades for thousands of times to meet the demands of million of customers all over the world;
    Three series to choose;
    Other warehouse equipment to choose;

    Better sale service of after-sale service:
    Active and professional salesperson;
    Warranty period of 1 years or 2000hrs, which occurs first;
    Dispatch professional engineer to arrange training courses or after sale maintenance if necessary.
