Supply Ability : | 500/Months |
Certification : | CE/ISO |
Brand Name : | snsc |
Price : | negotiable |
Delivery Time : | 30-45 Days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Specification | 388 | |
Overall dimension | Overall Operating Weight | 8200KG |
Transport Dimension | ||
L*W*H mm | 6050*2465*3100 mm | |
Wheel base | 2280mm | |
Min.Ground Clearance | 300mm | |
Performances | Bucket Capacity | 1.0m³ |
Breakout Force | 47KN | |
Loading Lifting Capacity | 2500KG | |
Bucket Dumping Height | 2760mm | |
Bucket Dumping Distance | 900mm | |
Digging Depth | 52mm | |
Backhoe Capacity | 0.3m³ | |
Max. Digging Depth | 4085mm | |
Swing Angle of Excavator Grab | 180° | |
Backhole Dumping Height | 3795mm | |
Backhole max digging depth | 4085mm | |
Max.Traction Force | 60KN | |
Engine | Model | Yuchai YC4A105Z-T20 |
Type | Turbocharging Four-Stroke | |
Cylinder-Inside Diameter*Stroke | 4-108×132 | |
Rated Power | 75KW | |
Rated Speed | 2200r/min | |
Min.Fuel Consumption | 230g/km.h | |
Max.Torque | 400N.m | |
Displacement | 4.8L | |
Steering System | Type | Hydraulic steering |
Model of Steering Device | BZZ5-250 | |
Steering Angle | ±36° | |
Min.turning radius | 6581mm | |
Axle | Model | WZZD75D |
Manufacturer | China Axle | |
Rated Loader of Axle | F22.5t R 18.5t | |
Transmission System | Gearbox | Mechanically operated hydraulic synchronized shifting |
Model | ZL15 | |
Type Gears | Single-stage Three Elements Two Gears Ahead, Two Gears Astern | |
Hydraulic torque converter | YJ290 | |
Inlet Pressure | 0.4Mpa-0. 65Mpa | |
Outlet Pressure | 1.5Mpa-1.8 Mpa | |
Cooling Method | Oil-cooling Pressure Circulation | |
Pump delivery | 40ml/r | |
Tyre | Front/Rear Model | 14-17.5/19.5L-24 |
Pressure of Front wheel | 0.4Mpa | |
Pressure of Back Wheel | 0.35Mpa | |
Max.Speed | 24Km/h | |
Brake System | Service Brake | Air Over Oil Caliper Brake, External Type, Self-regulation, Self-balance |
Parking Brake | Manual Brake | |
System pressure | Loading hydraulic system | 19Mpa |
digging hydraulic system | 19Mpa | |
Steering hydraulic system | 14Mpa |
SNSC Co., Ltd was established in January 2008, which has a
high-quality work team full of vigor and promise.
Our company mainly engaged in importing and exporting loders,
forklift, commercial vehicle, passenger vehicle, construction
machinery and spare parts as well as channels distribution for
vehicle electronics and exterior trim products.
After six years business exploration and resource integration, our
company has established long-term strategic cooperative relations
with many well known domestic manufacturers successively, adhering
to the concept of "profession, devotion, integrity and win-win" and
aims to become "integrated service providers in vehicles and spare
parts".
At the same time, we have established the terminal service stations
in the Middle East, North Africa and other regions to provide more
timely and accurate service to customers.
In 2013, in order to adapt to the needs of international market, we
registered SNSC as our brand. Based on high-quality products and
premium services, we persist in the management philosophy of
"success with quality & service creating value", and committed to
providing package solutions for customers in the vehicle industry.
We are willing to work with you to develop the market together!
Why choose SNSC?
Q1: How long is the Warranty for SNSC product?
![]() |
