brick diesel forklift with block clamp attachment
If you have any demands, warmly welcome to inquire Nicole more
detials,
Description:
1- Auto electric hydraulic transmission by TCM technology, just use
your finger can achieve the forklift's forward and backward;
2- Japan hydraulic system, by using Shimadzu brand Valve and Pump;
3- USA Eaton steering gear;
4- LED light& Protection , with long durability time;
5- Copper Radiator, with better heat radiation;
6- Red/yellow/green and all kinds of customized colors for your
reference;
7- Standard duplex mast, optional 3M-7M duplex / triplex mast;
8 - Standard China engine, optional Japan engine;
9-Red/ Yellow/ Green colors for your choice.
Common Optionals:
Japan Isuzu/Mitsubishi engine,Side shifter,Double front tires,Solid
tire,Double air filter,Vertical exhaust,fork extension,Cab,Fork
positioner.
Container Package Method:
Mini 4 ton diesel forklift package: 20GP container can hold 2
units,40GP container can hold 4 units;
Big 4 ton diesel forklift package: 40HC container can hold 3 units.
Specifications:
| Specifications | Unit | FD40 |
| 1 | Characteristics | Power | - | diesel |
| 2 | Rated Capacity | kg | 4000 |
| 3 | Center of load | mm | 500 |
| 4 | Lifting height | mm | 3000 |
| 5 | Free lifting height | mm | 85 | 146 |
| 6 | Forks L×W×H | mm | 1070x125x50 | 1070×150×50 |
| 7 | Tilt Forward/Backward | . | 6/12 |
| 8 | Min.turning radius | mm | 2700 | 2760 |
| 9 | Min.ground clearance(Mast) | mm | 120 | 160 |
| 10 | Overhead guard height | mm | 2090 | 2350 |
| 11 | Height from seat to overhead guard | mm | 1005 | 1040 |
| 12 | Front overhang | mm | 500 | 558 |
| 13 | Performance | Max.traveling speed(loaded) | km/h | 19.5 | 18 |
| 14 | Max.lifting speed(loaded/empty) | mm/s | 415/440 | 380/400 |
| 15 | Drawback pull/Grade ability | kN/% | 20/20 | 22/20 |
| 16 | Dimensions | Overall length (without fork) | mm | 2930 | 3060 |
| 17 | Overall width | mm | 1410 | 1490 |
| 18 | Mast lowered height | mm | 2155 | 2355 |
| 19 | Mast extended height | mm | 4275 | 4257 |
| 20 | Chassis | Tire | Front | - | 250-15-160PR | 8.25-15-14PR |
| 21 | Rear | - | 6.50-10-10PR | 7.00-12-12PR |
| 22 | Wheelbase | mm | 1900 | 2000 |
| 23 | Tread width | Front/Rear | mm | 1160/1065 | 1180/1190 |
| 24 | Curb weight | None-load | kg | 5300 | 6090 |
| 25 | Powertrain | Battery | Voltage/Capacity | V/Ah | 12/90 | (12/90)×2 |
| 26 | Engine | Model | - | XC498BPG | QC 4JR3 |
| 27 | Rated power | kw/r.p.m | 45/2500 | 48/2300 |
| 28 | Rated torque | Nm/r.p.m | 193/1600-1800 | 230/1600-1800 |
| 29 | Cylinder amount | - | 4 | 4 |
| 30 | Bore×Stroke | mm | 98x105 | 98x115 |
| 31 | Displacement | - | 3.168 | 3.47 |
| 32 | Fuel tank | L | 80 | 100 |
| 33 | Transmission | 1/1 automatic transmission |
| 34 | Working pressure | MPa | 17.5 | 18.5 |
Forklift Catalogue:
Diesel Forklift capacity is from 1.5 ton diesel forklift to 10 ton
diesel forklift;
(FD15/FD20/FD25/FD30/FD35/FD40/FD45/FD50/FD60/FD70/FD80/FD100)
Electric Forklift capacity is from 1.5ton battery forklift to
3.5ton battery forklift;
(FB15/FB20/FB25/FB30/FB35)
LPG&Gasoline Forklift capacity is from 1.5ton LPG forklift to
3.5ton LPG forklift;
(FL15/FL20/FL25/FL30/FL35)
Wearhouse material handling equipments include Electric Pallet
Truck (TB)/Electric Stacker(DB)/ Electric Reach Truck(YB)/Electric
Tractor(QB).
